The ATN BlazeHunter 650 LRF Thermal Monocular is an ATN Corp thermal monocular with 3.5-28x magnification and 50 mm objective.
How It Compares
Compare with the ATN BlazeHunter XD LRF 1280x1024 2-16x. Browse all thermal optics or the full ATN Corp range. Covered by the ATN factory warranty — check the current term with us before you buy.
Ideal For
- Night work where you need to see heat, not reflected light
- Picking up targets at distance — 2,600 yd
- Separating an animal from cold ground: 640x512 @ 12 µm VOx uncooled sensor at <18 mK
- Tracking something that is moving, at 50 Hz
Key Features
- Magnification: 3.5-28x
- Objective Lens: 50 mm
- Sensor: 640x512 @ 12 µm VOx uncooled
- NETD: <18 mK
- Detection Range: 2,600 yd
- Refresh Rate: 50 Hz
- Display: 0.41" 1440x1080 OLED
- Laser Rangefinder: Yes (range not published)
About This Model
- Sensor: 640x512 @ 12 µm VOx uncooled
- NETD: <18 mK
- Objective Lens: 50 mm
- Magnification: 3.5-28x
- Refresh Rate: 50 Hz
- IP67 rated
- Six color palettes
Technical Specifications
Type | Thermal Monocular |
Sensor | 640x512 @ 12 µm VOx uncooled |
NETD | <18 mK |
Objective Lens | 50 mm |
Magnification | 3.5-28x |
Refresh Rate | 50 Hz |
Detection Range | 2,600 yd |
Display | 0.41" 1440x1080 OLED |
Laser Rangefinder | Yes (range not published) |
Power | 2x swappable rechargeable, up to 14 h |
Weight | under 0.8 lb |
SKU / MPN / UPC | TIMNBLH650LRF / TIMNBLH650LRF / 658175126294 |
Warranty
Covered by the ATN factory warranty — check the current term with us before you buy.
US Shipping & Support
Shipped from D&R Sports Center in the USA with fast, tracked delivery. Questions on fit, mounting or which model suits your setup? Our team is glad to help before and after your purchase.
Frequently Asked Questions
What sensor does it use?
ATN Corp publishes the sensor as 640x512 @ 12 µm VOx uncooled. NETD is <18 mK — a lower figure means the sensor resolves smaller temperature differences, which shows as more detail.
How far can it detect?
ATN Corp states a detection range of 2,600 yd. That is a detection figure for a large object, not a recognition or identification distance.
Does it have a rangefinder?
Yes — a built-in laser rangefinder rated to Yes (range not published).
What battery does it take?
2x swappable rechargeable, up to 14 h.
Is this a genuine ATN Corp product?
Yes — factory-new ATN Corp, supplied through US distribution. The part number is TIMNBLH650LRF and the barcode is 658175126294.
What warranty does it carry?
Covered by the ATN factory warranty — check the current term with us before you buy.
