The Trijicon Ascent 1-4x24 Riflescope Black BDC Target Holds is a Trijicon rifle scope with 1-4x magnification and 24 mm objective.
How It Compares
Browse all rifle scopes or Trijicon rifle scopes.
Ideal For
- Shooters who want the reach of 1-4x on one rifle without swapping optics
- Low-light work, where the 24 mm objective is still gathering light at dusk
- Anyone who wants a clean BDC Target Holds reticle and no illumination battery to remember
- Hunters who want the reticle to stay the same size as they zoom
Key Features
- Magnification / Objective: 1-4x
- Objective: 24 mm
- Reticle: BDC Target Holds (etched, non-illuminated; Bullet Drop Compensating: Yes)
- Illumination: None - non-illuminated black etched reticle.
- Focal Plane: Second Focal Plane (SFP)
- Tube Diameter: 30 mm
- Click Value: 1/4 MOA per click
- Adjustment Range: 100 MOA total travel
About This Model
- Reticle: BDC Target Holds (etched, non-illuminated; Bullet Drop Compensating: Yes)
- Illumination: None - non-illuminated black etched reticle.
- Turrets: 1/4 MOA per click
- Warranty: Trijicon Limited Lifetime Warranty
What's Included
- Lens Cap, Scopecoat, Quick Reference Guide, Warranty Card, Vinyl Logo Sticker
Technical Specifications
Magnification / Objective | 1-4x |
Objective | 24 mm |
Tube Diameter | 30 mm |
Focal Plane | Second Focal Plane (SFP) |
Reticle | BDC Target Holds (etched, non-illuminated; Bullet Drop Compensating: Yes) |
Reticle Color | Black (etched) |
Illumination | None - non-illuminated black etched reticle. |
Click Value | 1/4 MOA per click |
Adjustment Range | 100 MOA total travel |
Parallax | Fixed (non-adjustable) |
Eye Relief | 2.6 - 3.9 in (66.0 - 99.1 mm) |
Field of View | 95 - 24.2 ft @ 100 yds (18 - 4.6 deg) |
Length | 10.4 in |
Weight | 15.9 oz |
Housing | 6061-T6 aluminum (6061 aircraft-grade on TR32/33/34/Ascent pages), hard-coat anodized |
Water Resistance | Waterproof - submersion depth 10 ft (3 m); nitrogen-filled/fogproof |
SKU / MPN / UPC | AT424-C-2800001 / AT424-C-2800001 / 719307402966 |
Warranty
Trijicon back this with their Limited Lifetime Warranty: the optical system and metal structure are covered against defects in materials and workmanship for the lifetime of the original owner.
US Shipping & Support
Shipped from D&R Sports Center in the USA with fast, tracked delivery. Questions on fit, mounting or which model suits your setup? Our team is glad to help before and after your purchase.
Frequently Asked Questions
Is it first or second focal plane?
Second Focal Plane (SFP). The reticle stays the same visual size as you zoom, so holdovers are calibrated at one magnification.
Which reticle does it have?
BDC Target Holds (etched, non-illuminated; Bullet Drop Compensating: Yes).
Is the reticle illuminated?
None - non-illuminated black etched reticle.
What is the parallax setting?
Fixed (non-adjustable).
Is this a genuine Trijicon product?
Yes — factory-new Trijicon, supplied through US distribution. The part number is AT424-C-2800001 and the barcode is 719307402966.
What warranty does it carry?
Trijicon back this with their Limited Lifetime Warranty: the optical system and metal structure are covered against defects in materials and workmanship for the lifetime of the original owner.
