EOTech EXPS3-DCR Holographic Weapon Sight Black – EXPS3-DCR

EOTech

EOTech EXPS3-DCR Holographic Weapon Sight Black – EXPS3-DCR

Name: EOTech EXPS3-DCR Holographic Weapon Sight Black – EXPS3-DCR
Brand: EOTech
SKU: EXPS3-DCR
Price: 815.00 USD
Availability: InStock

$815.00

EXPS3-DCR

In stock

Bundle & SaveChoose your quantity and save more when purchasing multiples.

Buy 1Standard price $815.00

Buy 2Save 5% ~~$1,630.00~~$1,548.50 total$774.25 eachYou save $81.50Save 5%

Buy 3Save 10% ~~$2,445.00~~$2,200.50 total$733.50 eachYou save $244.50Most Popular

Buy 4Save 15% ~~$3,260.00~~$2,771.00 total$692.75 eachYou save $489.00Best Value

Discount applied automatically in cart on eligible items. Cannot be combined with other product discounts.

Secure checkout

Questions about fit or compatibility?Our product support team can help before you order.Contact us

Orders ship within the United States only and are typically processed in 1–2 business days. Delivery estimates and any free-shipping offers are shown at checkout. We do not ship internationally. Read our full Shipping Policy.

Unused items in their original packaging may be returned within 30 days of delivery. Optics that have been mounted or used may be inspected. Email support@dnrsports.com to start a return. Read our full Return & Refund Policy.

Products are covered by their manufacturer's warranty; coverage and length vary by brand. We'll help you start a claim if needed — email support@dnrsports.com. Read our Warranty page.

The D&R Standard

Secure Online Ordering
Carefully Selected Equipment
Knowledgeable Product Support
Manufacturer Warranty Information Available

Product Overview

Overview

The EOTech EXPS3-DCR Holographic Weapon Sight Black puts a Danger Close chevron reticle in front of you the instant the gun comes up. Holographic projection means the reticle stays usable even if the window is partly obscured, and it does not wash out at speed. It carries dedicated night vision settings alongside its daylight range, and the whole sight runs from 1 x CR123 lithium battery.

How It Compares

Close alternatives: EOTech EXPS3-DCR Holographic Weapon Sight Tan. Also consider EOTech EXPS3-0 Holographic Weapon Sight, EOTech EXPS3-0 Holographic Weapon Sight Tan. Browse all Holographic Weapon Sights or read our buying guide.

Ideal For

Close-quarters and rapid target acquisition
AR-pattern carbines and defensive rifles
Pairing with a 3x or 5x magnifier

Key Features

Reticle — DCR (Danger Close Reticle): 68 MOA ring with the TOP portion of the ring removed (top cutout), a 1 MOA centre dot
Night vision — Yes
Brightness — 20 daylight settings + 10 additional settings for Gen I-III+ night vision devices
Battery life — 1,000 continuous hours at nominal setting 12 at room temperature
Mount — 1" Weaver or MIL-STD-1913 rail
Water resistance — Water resistant to 33 ft (10 m) depth

Technical Specifications

Optic Type	Holographic Weapon Sight (HWS) - transmission holography
Magnification	1X
Reticle	DCR (Danger Close Reticle): 68 MOA ring with the TOP portion of the ring removed (top cutout), a 1 MOA centre dot, and an easy-to-locate chevron replacing the bottom of the ring. Zeroed at 50 yd for .223/5.56 it gives aiming points out to 200 yd plus a 7 yd close-range solution at the chevron point
Reticle Color	Red
Night Vision Compatible	Yes
Brightness Settings	20 daylight settings + 10 additional settings for Gen I-III+ night vision devices
Parallax	Reticle projected at 200 m, which minimises parallax
Eye Relief	Unlimited
Window Size	1.20" x 0.85" (30 x 23 mm)
Field of View	30 yds at 100 yds (at 3" eye relief)
Adjustment Increment	Approx. 0.5 MOA per click (1/2" at 100 yds)
Windage Travel	+/- 40 MOA travel
Elevation Travel	+/- 40 MOA travel
Mount	1" Weaver or MIL-STD-1913 rail
Mount System	Integrated adjustable locking quick-detach lever, 7 mm raised base
Co-Witness Height	Lower 1/3 co-witness
Battery	1 x CR123 lithium battery
Battery Life	1,000 continuous hours at nominal setting 12 at room temperature
Water Resistance	Water resistant to 33 ft (10 m) depth
Operating Temperature	-40 F to 140 F (-40 C to 60 C)
Dimensions	3.8" x 2.3" x 2.9" (96.5 x 58.4 x 73.7 mm)
Weight	11.2 oz (317.5 g)
Finish	Black (EXPS3-DCR); Tan available as separate SKU EXPS3-DCRTAN
Country of Origin	Made in USA
SKU / MPN / UPC	EXPS3-DCR / EXPS3-DCR / 672294601036

US Shipping & Support

Shipped from the USA by D&R Sports Center. Questions on fitment, reticle choice or mounting are answered by people who use this equipment — get in touch before you order if you are unsure.

Frequently Asked Questions

What reticle does the EXPS3-DCR use?
DCR (Danger Close Reticle): 68 MOA ring with the TOP portion of the ring removed (top cutout), a 1 MOA centre dot, and an easy-to-locate chevron replacing the bottom of the ring. Zeroed at 50 yd for .223/5.56 it gives aiming points out to 200 yd plus a 7 yd close-range solution at the chevron point

Is it night vision compatible?
Yes — it has dedicated night vision brightness settings.

What battery does it take?
1 x CR123 lithium battery

How long does the battery last?
1,000 continuous hours at nominal setting 12 at room temperature

Can I use it with a magnifier?
Yes. It pairs with EOTech's G33, G43 and G45 magnifiers on a switch-to-side mount.
